NanoLume
Boca__NANOLUME QUICKSHIP_white.jpgNanoLume
Micro Profile LED Task and Cove Fixture
Boca Lighting and Control’s NanoLume has a streamlined profile. It is a line voltage fixture perfect for Cove Lighting or Task Lighting areas where space, budget and energy are a factor. Boca’s CleanDim® technology ensures even dimming from 0-100%. The NanoLume can be fabricated with a range of color temperature choices, affording a multitude of options. The housing is a high temperature ABS plastic with a durable white or black finish, making it temperature and abrasion resistant.
Key Features
Key Features
- Line voltage fixture with CCT options
- Compact architectural profile
- Perfect for cove and task lighting
Boca Lighting and Control’s NanoLume has a streamlined profile. It is a line voltage fixture perfect for Cove Lighting or Task Lighting areas where space, budget and energy are a factor. Boca’s CleanDim® technology ensures even dimming from 0-100%. The NanoLume can be fabricated with a range of color temperature choices, affording a multitude of options. The housing is a high temperature ABS plastic with a durable white or black finish, making it temperature and abrasion resistant.
Key Features
Key Features
- Line voltage fixture with CCT options
- Compact architectural profile
- Perfect for cove and task lighting
The Nanolume is ideal for these applications:
- Cove
- Wall Washing / Grazing
- Millwork
- Under-cabinet
- Task
Resources
The Nanolume is ideal for these applications:
- Cove
- Wall Washing / Grazing
- Millwork
- Under-cabinet
- Task
What applications is this best for?
NanoLume-style fixtures are commonly used in millwork, coves, reveals, shelves, and architectural accents.
Can runs be continuous?
Yes, continuous runs are typically supported using compatible joiners, channels, and power feeds.
NanoLume-style fixtures are commonly used in millwork, coves, reveals, shelves, and architectural accents.
Can runs be continuous?
Yes, continuous runs are typically supported using compatible joiners, channels, and power feeds.
- Specifier / Lighting Designer
- High 90 CRI ensures exceptional color rendering for premium architectural environments.
- Broad CCT selection from 2000K to 4000K meets diverse design requirements.
- Precise 15x40 optic provides controlled light distribution for specific task areas.
- Architect
- Micro profile allows for seamless concealment in minimal architectural details.
- Streamlined design integrates perfectly into millwork, reveals, and architectural coves.
- High-temperature ABS housing offers durable white or black finish options.
- Engineer
- Line voltage fixture simplifies electrical design by eliminating external remote drivers.
- Supports 0-10V, DALI, DMX, and Phase dimming for ultimate control compatibility.
- CleanDim technology ensures smooth, flicker-free dimming performance from 0-100%.
- Installer / Contractor
- Line voltage operation reduces installation time and simplifies power feed requirements.
- Flexible swivel and hinge mounting options provide easy fixture positioning.
- Compact profile simplifies installation within shallow architectural spaces.
- Facility Manager / Owner
- Energy-efficient performance helps reduce operational costs.
- Five-year warranty ensures long-term reliability and reduced maintenance.
- Durable LED construction minimizes replacement frequency and lifecycle costs.
Beam Angle
- 15x40
- 120
CCT
- 2000K
- 2400K
- 2700K
- 3000K
- 3500K
- 4000K
CRI
- 90
Color / Finish
- Black
- White
Dimensions
- L: 36 In.
- L: 42 In.
- L: 30 In.
- L: 48 In.
- L: 60 In.
- L: 66 In.
- L: 24 In.
- L: 72 In.
- L: 54 In.
- L: 12 In. W: 1.03 In. H: 0.82 In.
- L: 18 In.
Dimming Protocol
- 0-10 V
- DALI
- DMX
- Forward Phase
- Reverse Phase
Dimming Range
- 0-100%
Lamp Source
- LED
Listings
- cULus
Lumens
- 432
- 510
- 560
- 588
- 618
- 636
Materials
- ABS
- Plastic
Mounting
- Fixed
- Hinge
Ratings & Compliance
- Build America Buy America (BABA)
- Buy American Act (BAA)
- IP50
- JA8
- Made in America
- RoHS
- Title 24
Static LED Color
- White
Voltage
- 230-277 V
- 90-120 V
Warranty
- 5 yr
Watts
- 3
- 6
Additional Details
- Specifier / Lighting Designer
- High 90 CRI ensures exceptional color rendering for premium architectural environments.
- Broad CCT selection from 2000K to 4000K meets diverse design requirements.
- Precise 15x40 optic provides controlled light distribution for specific task areas.
- Architect
- Micro profile allows for seamless concealment in minimal architectural details.
- Streamlined design integrates perfectly into millwork, reveals, and architectural coves.
- High-temperature ABS housing offers durable white or black finish options.
- Engineer
- Line voltage fixture simplifies electrical design by eliminating external remote drivers.
- Supports 0-10V, DALI, DMX, and Phase dimming for ultimate control compatibility.
- CleanDim technology ensures smooth, flicker-free dimming performance from 0-100%.
- Installer / Contractor
- Line voltage operation reduces installation time and simplifies power feed requirements.
- Flexible swivel and hinge mounting options provide easy fixture positioning.
- Compact profile simplifies installation within shallow architectural spaces.
- Facility Manager / Owner
- Energy-efficient performance helps reduce operational costs.
- Five-year warranty ensures long-term reliability and reduced maintenance.
- Durable LED construction minimizes replacement frequency and lifecycle costs.
What applications is this best for?
NanoLume-style fixtures are commonly used in millwork, coves, reveals, shelves, and architectural accents.
Can runs be continuous?
Yes, continuous runs are typically supported using compatible joiners, channels, and power feeds.
NanoLume-style fixtures are commonly used in millwork, coves, reveals, shelves, and architectural accents.
Can runs be continuous?
Yes, continuous runs are typically supported using compatible joiners, channels, and power feeds.
