Nano Warm Dim-QS
Boca__NANO WARM DIM QUICKSHIP_warm dim.jpgNano Warm Dim-QS
Micro Profile LED Task and Cove Fixture with Warm Dim | QuickShip
The popular NanoLume can now be specified with Boca Lighting and Controls’s Dim to Warm technology, Nano Warm Dim. Standard range shifts the color temperature from 2000K to 3000K as the fixture is dimmed. Other color range options are available to meet any project need. Boca’s patented CleanDim® technology ensures even dimming from 0-100%. See specification sheet and ordering guide for Quick Ship terms.
Key Features
Key Features
- Available for Quick Ship
- Fixed or hinged mounting
- Compact architectural design
The popular NanoLume can now be specified with Boca Lighting and Controls’s Dim to Warm technology, Nano Warm Dim. Standard range shifts the color temperature from 2000K to 3000K as the fixture is dimmed. Other color range options are available to meet any project need. Boca’s patented CleanDim® technology ensures even dimming from 0-100%. See specification sheet and ordering guide for Quick Ship terms.
Key Features
Key Features
- Available for Quick Ship
- Fixed or hinged mounting
- Compact architectural design
The Nano Warm Dim-QS is ideal for these applications:
- Cove
- Wall Washing/Grazing
- Millwork
- Under-cabinet
- Task
Resources
The Nano Warm Dim-QS is ideal for these applications:
- Cove
- Wall Washing/Grazing
- Millwork
- Under-cabinet
- Task
What dimming protocols are supported?
Forward/Reverse Phase Line Dimmer, Compatible with 0-10V, DALI, DMX
How quickly can it ship?
10 business days after approvals.
Forward/Reverse Phase Line Dimmer, Compatible with 0-10V, DALI, DMX
How quickly can it ship?
10 business days after approvals.
- Specifier / Lighting Designer
- High 90 CRI ensures exceptional color rendering for premium architectural interiors.
- Precise beam control with 10x10, 15x40, or 120-degree optical options.
- Dynamic warm dimming from 3000K down to 2000K for perfect ambiance.
- Architect
- Ultra-slim micro profile allows for seamless concealment within tight architectural details.
- Compact architectural design integrates flawlessly into high-end coves and millwork.
- Minimalist aesthetic maintains the integrity of the building’s design and structure.
- Engineer
- Universal dimming compatibility including DALI, DMX, 0-10V, and Reverse Phase.
- Patented CleanDim® technology guarantees smooth, flicker-free dimming from 0-100%.
- Certified for performance with JA8 compliance and cULus listing for safety.
- Installer / Contractor
- Versatile fixed or hinged mounting options simplify installation in complex spaces.
- Quick Ship program delivers fixtures in just 10 business days for tight schedules.
- Low-profile design and flexible mounting ensure hassle-free placement in narrow channels.
- Facility Manager / Owner
- Energy-efficient 6W LED performance significantly reduces long-term operational and utility costs.
- Robust 5-year warranty provides peace of mind and minimizes maintenance concerns.
- Long-lasting LED technology ensures years of reliable, high-quality architectural illumination.
Beam Angle
- 10x10
- 15x40
- 120
CCT
- 2000K
- 3000K
CRI
- 90
Color / Finish
- Black
- White
Dimensions
- L: 36 In.
- L: 42 In.
- L: 30 In.
- L: 48 In.
- L: 60 In.
- L: 66 In.
- L: 24 In.
- L: 72 In.
- L: 54 In.
- L: 12 In. W: 1.03 In. H: 0.82 In.
- L: 18 In.
Dimming Protocol
- DALI
- DMX
- Reverse Phase
Lamp Source
- LED
Listings
- cULus
Materials
- ABS
- Plastic
Mounting
- Fixed
- Hinge
Ratings & Compliance
- Build America Buy America (BABA)
- Buy American Act (BAA)
- IP50
- JA8
- Made in America
- RoHS
- Title 24
Special Programs
- Quick Ship
Static LED Color
- White
Voltage
- 230-277 V
- 90-120 V
Warranty
- 5 yr
Watts
- 6
Additional Details
- Specifier / Lighting Designer
- High 90 CRI ensures exceptional color rendering for premium architectural interiors.
- Precise beam control with 10x10, 15x40, or 120-degree optical options.
- Dynamic warm dimming from 3000K down to 2000K for perfect ambiance.
- Architect
- Ultra-slim micro profile allows for seamless concealment within tight architectural details.
- Compact architectural design integrates flawlessly into high-end coves and millwork.
- Minimalist aesthetic maintains the integrity of the building’s design and structure.
- Engineer
- Universal dimming compatibility including DALI, DMX, 0-10V, and Reverse Phase.
- Patented CleanDim® technology guarantees smooth, flicker-free dimming from 0-100%.
- Certified for performance with JA8 compliance and cULus listing for safety.
- Installer / Contractor
- Versatile fixed or hinged mounting options simplify installation in complex spaces.
- Quick Ship program delivers fixtures in just 10 business days for tight schedules.
- Low-profile design and flexible mounting ensure hassle-free placement in narrow channels.
- Facility Manager / Owner
- Energy-efficient 6W LED performance significantly reduces long-term operational and utility costs.
- Robust 5-year warranty provides peace of mind and minimizes maintenance concerns.
- Long-lasting LED technology ensures years of reliable, high-quality architectural illumination.
What dimming protocols are supported?
Forward/Reverse Phase Line Dimmer, Compatible with 0-10V, DALI, DMX
How quickly can it ship?
10 business days after approvals.
Forward/Reverse Phase Line Dimmer, Compatible with 0-10V, DALI, DMX
How quickly can it ship?
10 business days after approvals.
