NanoWedgeNanoWedge

NanoWedge

Micro Profile LED Closet & Corner Light

Boca Lighting and Controls’s NanoWedge is a small profile line voltage fixture well suited to installations areas where space and energy consumption are of concern. The NanoWedge offers an optional choice of Occupancy or IR Sensor activation** or is compatible with all Boca standard line voltage dimming protocols. The fixture can be fabricated with a range of color temperature and lens choices.
Specification Sheet Find an Agent
ResourcesInspirationSimilar ProductsCollections

Resources

Photometry

Beam Angle

  • 120

CCT

  • 2400K
  • 2700K
  • 3000K
  • 3500K
  • 4000K
  • 5000K

CRI

  • 90 CRI

Color / Finish

  • Clear Anodized Aluminum

Controls Options

  • Infra Red Sensor
  • Occupancy Sensor

Dimensions

  • H: 1.34 In. L: 15 In. W: 1.26 In.

Dimming Protocol

  • 0-10 V
  • Forward Phase
  • Reverse Phase

Lamp Source

  • LED

Listings

  • cULus

Materials

  • Aluminum

Ratings & Compliance

  • Build America Buy America Act (BABAA)
  • IP50
  • JA8
  • Made in America
  • RoHS
  • Title 24

Static LED Color

  • White

Voltage

  • 120 V

Warranty

  • 5 yr

Watts

  • 4 w
  • 8 w
